When a rebuild stalls because one clutch pack is worn and the frictions are scattered across three separate orders, this kit puts all seventeen plates in a single box ready to go to the bench. What sets this Friction Kit apart is the combination of three distinct clutch applications in one SKU: the direct and intermediate clutch frictions for AXOD and AXODE AX4S units going back to 1986, the forward clutch hi-energy frictions specific to AXODE AX4S and AX4N units from 1991 forward, and the reverse clutch frictions covering the full AXOD AXODE AX4S AX4N range.
The kit contains exactly 17 pieces across three part numbers. Nine frictions measure .065 inch with 96 teeth and cover the direct intermediate clutch position. Four forward clutch frictions are hi-energy spec at .065 inch with 57 teeth, built for the 1991-and-up AX4S and AX4N variants. The remaining four reverse clutch frictions measure .069 inch and fit AXOD, AXODE, AX4S, and AX4N applications from 1986 on.
This is a Friction Kit only. It does not include steel reaction plates, seals, gaskets, o-rings, Automatic Transmission Filter, bands, or pistons. If your rebuild needs those components, you will need to source them separately before the unit goes back together.
REMCO has been working in automatic transmission parts since 1991. Each kit is assembled here by hand, part by part against its pick list, and the same list ships inside the box so the tech at the bench can verify the count before opening anything. Total weight is 2 lb.
Confirm the unit code on the case, the model year, and which clutch positions need service before placing the order. AXOD, AXODE, AX4S, and AX4N share a family but differ in internal specs.
- Consolidating all three clutch friction sets into one order cuts bench time and keeps the rebuild moving without waiting on separate shipments.
- This kit contains friction plates only. It does NOT include steel plates, seals, gaskets, Automatic Transmission Filter, bands, or any other components. Review your parts list before ordering.
- Seventeen friction plates covering three clutch packs: 9 direct/intermediate clutch frictions (.065 96T), 4 forward hi-energy frictions (.065 57T), and 4 reverse clutch frictions (.069), all in one box.
- Contents: 9x AXOD AXODE AX4S direct/intermediate clutch friction [86-UP], 4x AXODE AX4S AX4N forward clutch hi-energy [91-UP], 4x AXOD AXODE AX4S AX4N reverse clutch friction [86-UP]. Total: 17 pieces. Weight: 2 lb.
- Before ordering, confirm the exact unit code stamped on the case, the production year, and which clutch packs you are replacing. AXOD, AXODE, AX4S, and AX4N are distinct variants with different specifications.
What's in the box
- 9 x Friction Clutch Plate, AXOD AXODE AX4S Direct Intermediate [.065" Thick 96]
- 4 x Friction Clutch Plate, AXOD AXODE AX4S AX4N Reverse [.069" Thick]
- 4 x Friction Clutch Plate, AXODE AX4S AX4N Forward High Energy [.065" Thick] [57 Teeth]
Compatible vehicles
- Fits Taurus [86-90], Continental [88-90], Sable [86-90].
