When friction plates in the JF506E wear past spec, no adjustment corrects the slippage: the plates have to come out and fresh material has to go in. This Friction Kit from REMCO puts all six clutch pack friction sets in one box, sized and counted for the JF506E and JF506 (09A) built from 1998 forward, so the technician does not have to source each plate separately and risk mixing up specs.
The kit contains 28 friction plates divided across six distinct clutch packs. The low clutch pack gets 7 plates at .070 thickness, 30 teeth, 5-7/16 inch OD. The low reverse clutch also gets 7 plates, but these run .071 thick, 32 teeth, and 6.500 inch OD - a different plate entirely, easy to confuse when ordering loose parts. High clutch is covered by 5 plates at .063 thick, 24 teeth, 4.400 OD. Direct clutch takes 4 plates at .069 thick, 24 teeth, 4 inch OD. The 2-4 brake clutch uses 3 plates at .063 thick, 32 teeth, 7-1/2 OD. Reverse clutch closes out the kit with 2 plates at .063 thick, 32 teeth, 6-1/8 OD.
This is a Friction Kit: it does not include steel separator plates, seals, gaskets, Automatic Transmission Filter, band, or any other component. If your rebuild also needs those parts, they are sold separately. Confirm you need frictions only before placing the order.
REMCO has worked in automatic transmission parts since 1991. Every kit is assembled here by hand, plate by plate, verified against its own parts list before the box is sealed. That list ships inside the box so the technician can check off each piece at the bench. Total shipped weight is approximately 2 lb.
- Restoring clutch pack engagement on a slipping or burned JF506E keeps the unit from destroying itself further during diagnosis and teardown.
- This kit covers friction plates only: it does not include steel plates, seals, gaskets, Automatic Transmission Filter, or band. Check your parts list before ordering to avoid a return.
- Six distinct clutch packs are addressed in one box: low clutch 7-plate, low reverse 7-plate, high clutch 5-plate, direct clutch 4-plate, 2-4 brake 3-plate, and reverse clutch 2-plate.
- 28 friction plates total across 6 partidas: 7x low clutch .070 30T 5-7/16 OD, 7x low reverse .071 32T 6.500 OD, 5x high clutch .063 24T 4.400 OD, 4x direct .069 24T 4 OD, 3x 2-4 brake .063 32T 7-1/2 OD, 2x reverse .063 32T 6-1/8 OD. Kit weighs 2 lb.
- Before purchasing confirm your unit code is JF506E or JF506 (catalog reference 09A), verify the model year falls within the [98-UP] range, and cross each plate spec against your teardown measurements.
What's in the box
- 7 x Friction Clutch Plate, R4AXEL Low [.070" Thick] 30 Teeth [5 7 16 OD]
- 7 x Friction Clutch Plate, Low Reverse [.071" Thick] 32 Teeth [6.500" OD] RE4F04A 4F20E
- 5 x Friction Clutch Plate, JF506E High [.063" Thick] 24 Teeth [4.400" OD]
- 4 x Friction Clutch Plate, Direct [.069" Thick] 24 Teeth [4 OD] JF506E
- 3 x Friction Clutch Plate, 2-4 Brake [.063" Thick] 32 Teeth [7 1-2od] JF506E
- 2 x Friction Clutch Plate, JF506E Reverse [.063" Thick] 32 Teeth [6-1 8 OD]
Compatible vehicles
- Fits Golf [02-05], GTI [02-05], Jetta [02-05], Sharan [00-10].
| FRICTION MODULE ALLOMATIC (98-UP) JF506 |
